XPress 1000 SC Riveter PushPull – Full Set -Mercedes Benz MB3 (700005SC)

XPress 1000 SC Riveter PushPull – Full Set Mercedes-Benz MB3 (700005SC)

The XPress 1000 SC Riveter PushPull Full Set Mercedes-Benz MB3 is a comprehensive modular riveting system built for professional bodyshop use. Specifically, it features a force-supporting retraction cylinder designed for punching hard and ultra-hard structural parts. As a result, technicians can carry out Mercedes-Benz approved joining processes on modern vehicle body structures with confidence.

This Wielander & Schill riveting system handles a wider range of applications than the standard set. For instance, it supports extraction of self piercing rivets, installation of flow form rivets, solid self piercing rivets, blind rivets and blind rivet nuts. Additionally, it can be used for backshaping and calibration tasks.

XPress 1000 SC Full Set MB3 Applications

• Extraction of self piercing rivets (SPR)
• Installation of flow form rivets
• Installation of solid self piercing rivets
• Installation of blind rivets
• Installation of blind rivet nuts
• Backshaping
• Calibration

XPress 1000 SC Full Set MB3 Scope of Delivery

• 1 x 700090 PowerPack – XPress 1000 SC
• 1 x 700105 PushPull PP 90 – Retraction cylinder
• 1 x 700100 BR 20 Blind rivet adapter
• 1 x 700101 BR 50 Blind rivet adapter
• 1 x 700110 BRN 50 Blind rivet nut adapter
• 1 x S700070 C-Arm GC 80/40
• 1 x 700080SC C-Arms – 4-piece set (S700071 + S700072)
• 1 x 700205 Tool Box RS-07 – Mercedes-Benz
• 1 x 700201 Tool Box RS-04 – BRN
• 1 x Transport case
• 1 x Instruction manual

XPress 1000 SC Technical Specifications

• Force: 10 kN / 126 kN
• Stroke: 16 mm / 25 mm
• Work window: Max. 140 × 240 mm
• Operating pressure: 8 bar
• Air quality: ISO 8573-1
• Max. oil volume: 120 cm³
• Oil type: HLP 22 – HLP 36
• Operating temperature: 5 to 50 °C
• Sound pressure level: 75 dB(A)
• Vibration: < 2.5 m/s²
• Material: Aluminium, plastic and steel

Why Choose the XPress 1000 SC Full Set Mercedes-Benz MB3?

Modern Mercedes-Benz vehicles use increasingly complex multi-material body structures. Therefore, bodyshops need riveting equipment that can handle hard and ultra-hard materials reliably. The XPress 1000 SC Riveter PushPull Full Set Mercedes-Benz MB3 delivers up to 126 kN of force and includes dedicated blind rivet and blind rivet nut adapters. Consequently, it meets the demands of the latest Mercedes-Benz repair specifications.

Compared to the standard set, this full set adds three additional adapters. Firstly, the BR 20 and BR 50 blind rivet adapters cover a range of blind rivet sizes. Secondly, the BRN 50 blind rivet nut adapter enables secure threaded fastening. Furthermore, the additional Tool Box RS-04 for BRN consumables keeps everything organised and ready for use.

Moreover, the patented Smart Control system provides a force-free fast approach stroke. In other words, the tool advances to the workpiece without applying pressure until the correct position is reached. As a result, the risk of workpiece damage is significantly reduced during every riveting operation.

Bodyshop Solutions is an authorised UK supplier of Wielander & Schill riveting systems. Simply call us on 01327 300700 for expert advice, pricing or to arrange a demonstration.
