TECHNOMIG 223 TREO SYNERGIC + SPOOL GUN (816120)

Item Number:

816120

A fast, easy to use MIG welder with 2 torches and a spool gun, that will give excellent welding results.

• Fast and easy to use – using One Touch LCD Technology
• Immediate use of 3 different material spools using 3 different torch types (2 MIG torches + 1 Spool Gun)
• Superb welding of steel, HSS high strength steels, stainless steel, galvanised and aluminium
• ATC technology enables excellent welding on thin materials
• Single phase (230 Volts)
• 20 Amps to 220 Amps output

01327 300700

Call Us for Expert Advice

Price available on request

Lease purchase options available​

Microprocessor controlled MIG-MAG / FLUX / BRAZING / MMA / TIG DC-Lift multiprocess inverter welding machine.

It is particularly suitable for bodywork and allows the immediate use of three different torches , two traditional mig and a spool gun.

This feature allows direct intervention on different materials without changing torches and wire reels, confirming Technomig 223 Treo the unique solution for all repair and maintenance needs. Traditional mig torches are dedicated to welding steel, high-strength HSS steels, stainless steel and brazing galvanized sheets, while the spool gun torch is suitable for aluminum even at a long distance from the generator.

The rapid SYNERGIC adjustment of the welding parameters, thanks to the ONE TOUCH LCD SYNERGY technology, makes the product very easy to use. The ATC technology, Made in Telwin, allows you to easily obtain excellent welds on thin thicknesses thanks to an advanced arc control.

It is also possible to manually intervene on the length of the arc: this adjustment will allow you to change the shape of the weld bead according to the style of the welder.

The ONE TOUCH LCD graphic display allows a better reading of all welding parameters.

Features: 17 synergic curves set up * welding parameters displayed on LCD display * adjustments: wire rising ramp, electronic ballast, wire final burn time (burn back), post gas * 2/4 stroke operation selection, spot * thermostatic, overvoltage, undervoltage, overcurrent, motorgenerator (+/- 15%) protections.

Complete with 2 MIG-MAG torches, SPOOL GUN, cable and ground clamp.
• Fast and easy to use – using One Touch LCD Technology
• Immediate use of 3 different material spools using 3 different torch types (2 MIG torches + 1 Spool Gun)
• Superb welding of steel, HSS high strength steels, stainless steel, galvanised and aluminium
• ATC technology enables excellent welding on thin materials
• Single phase (230 Volts)
• 20 Amps to 220 Amps output

Single Phase 230v
Power Factor (cosphi) 0.7 Mains frequency 50/60 HzD Usable electrodes in DC 1.6 -4mm Current range 20-220A Steel welding wire diameter 0.6-1mm Maximum current DC (EN 60974-1)180 @ 20% Ainox welding wire diameter 0.8-1mm DC current 100A Aluminium welding wire diameter 0.8-1mm Max no load voltage 78V Flux cored welding wire diameter 0.8-1mm Max absorbed currrent 32A Brazing wire diameter 0.8mm-1mm Absorbed current at 60% - Max 15A Protection Degree IP23 Max absorbed power 5kW Dimensions 87 x 53 x 166.5 cm Absorbed power at 60% 2.2W Weight 55kg Efficiency 84% EAN CODE 800489793816 5

2 x MIG-MAG torches (3m) M6 Spool Gun Toledo 250 work clamp Cable 16 MMQ 3m
