Item Number:
The InvertaPuls IP 7-2 impresses with its effortless operation thanks to a simple, easy-to-understand interface. The four extra-large 37 mm drive rollers provide a large contact surface for the welding wire, which enables optimum wire feed. With two torches, ergonomic torch removal and a slim design, the IP 7-2 is perfect for any use in body shops.
Features
• Automatic torch recognition
• Higher welding speed
• Lower heat input
• Very good gap bridging
• Less material distortion
• Automatic “hold function” of the welding parameters
• Welding programmes for: MIG soldering (CuSi3, AlBz8, CuAl8) | steel/stainless steel | aluminium | TIG | flux-cored wire | electrode welding• Lower heat input
• Saving of individual welding programs
• Integrated interface for software updates
Equipped with:
1 x 337219 Wire feed rollers | steel | 0.6 mm & 0.8mm | PU: 2 pcs.
1 x 337220 Wire feed rollers | steel | 0.8 mm & 1.0 mm | PU: 2 pcs.
1 x 308110 Torch 3G | Steel welding | 3.0 m
1 x 308116 Torch 3G | MIG soldering (CuSi3) | 3.0 m
1 x 304053 Ground cable with clamp | 5 m | 35 mm² | SK 35
2 x 311042 Pressure reducer ProControl | 200 bar (only DE and AT)
1 x 311044 Double branch valve 1/4″ for manometer (only DE and AT)
1 x 307060 Contact tips M6 x 28 mm | 10-piece set
1 x User manual
| Current setting range: | 10 – 280 A |
|---|---|
| Effectiveness: | 86 % |
| Fuse: | 16 A (slow) |
| Length × width × height: | 920 x 650 x 930 mm |
| Mains connection (Cu): | 4 × 2,5 mm² |
| Mains voltage: | 3 ~ 400 V |
| Mark of conformity: | CE |
| Open circuit voltage: | 96 V (MIG) |
| Operating temperature: | -10 bis 40 °C |
| Power factor: | 0,75 |
| Protection class: | IP 23 |
| Sound pressure level: | 66 dB(A) |
| Voltage setting range: | 10 – 50 V |
| Weight: | 67 kg |
| Wire speed range: | 0,5 – 22 m/min |
This welding machine has a very simple, self-explanatory and intuitive operation – 2-button handling.
Equipped with a robust, industry-compliant, powder-coated sheet steel housing, 2x 4-roller drive with extra-large 37 mm drive rollers for a large welding wire drive support surface for optimum wire feed.
Ergonomic torch removal and narrow housing construction ensure efficient use in any body shop.
Optional with connection for PushPull hose package and front wheel spacer (item N° 337236) for the use of 2x 50 litre gas bottles.
Also available in 3x220V configuration – item N° 332026 (steel / brazing kit) and 332027 (steel / ALU kit)
Item N°: 331026
ertificatons: CE
Open-circuit voltage: 96V (MIG,TIG) / 72V (MMA)
Net weight: 79.80, 62,000 kg
Power supply (Cu): 4×2,5 mm² (4×4 mm²), 4×2,5 mm²
Fuse: 16A (25A) träge, 16 A time-lag
Supply voltage: 3×400 V (3x200V), 3×400 V (+/- 15%)
Temperature range: -40…+80°C
Drahtgeschwindigkeit: 0,5-22 m/min.
Voltage range: 10-50 V / 0.1 step
Continuous output: 200 Amp / 24V
Working temperature: -10…+40°C
Packing unit: 1 Stück / pc.
Gross weight: 67,000 kg, 79.80
Lenght: 4 m (power cable), 10 m (power cord)
Draktvorschubrollen Ø: 37 mm
Efficiency: 85 %
LängexBreitexHöhe: 920x350x740 mm
Power factor: 0.75
Temperature class: H (180°C)
Protecton category: IP23
1x welding machine IP 7-2 400V (200V) incl.castors
1x gas bottle holder for 2x 20 litres
1x 3G steel hose/torch package, 3m
1x set of DV rollers for steel 0,6 / 0,8 mm
1x 3G steel hose/torch package, 3m
1x set of DV rollers for steel 0,8 / 1,0 mm
1x nozzle starter set (5x 2 pcs)
1x ground cable
1x instruction manual
